1D1-8 COMPRESSOR OVERHAUL EXCEPT TAIWAN 8. Drive Plate Bolt Using drive plate holder to prevent the drive plate Tighten: Drive plate bolt to 15 N ⋅m (0.5 kg⋅m / 11 lb⋅ft) After tightening the bolt, check to be sure the pulley Thickness 0.1 mm (0.0039 in) 0.3 mm (0.0118 in) 0.5 mm (0.0197 in) N1A0150E 5-8840-0117-0 N1A0143E N1A0152E |
