Automatic Transmission – 4L60E – General Information
Page 7C1–20
8 Special
Tools
The following pages list and illustrate the special service tools required. The tools are classified into the following
categories:
Mandatory:
When required to perform routine maintenance operations and adjustments, or are required to carry out
fault diagnosis procedures.
Desirable:
These tools should be considered for purchase since their use will greatly facilitate performing designated
tasks and permit achievement of standard times.
Unique:
These tools are those that must be employed when overhauling major assemblies or performing relatively
large tasks.
Available:
Are those tools that are of a general nature for which commercially available equivalents exist, or tools
which have had previous application.
Unless otherwise specified, all tools are available from:
SPX Australia PTY. LTD.
Service Solutions
28 Clayton Road
Notting Hill, Victoria, 3168
Telephone: (03) 9544 6222
Facsimile: (03) 9544 5222
Tool Number
Illustration
Description
Tool Classification
700-4208
Pass-Thru Connector Remover
Used to release the four locking tangs
on the Pass-Thru connector from the
transmission case.
Previously released
Desirable
J6125-1B
Slide Hammer
Used for a number of bush removal
operations.
Previously released
Unique
J8092
Driver Handle
Used for a number of bush installation
operations.
Previously released
Unique
J8433
Puller
Used with J21427-01 to remove the
output speed sensor ring from the
main shaft.
Previously released
Unique
J8763-02
Holding Fixture
Used in conjunction with holding
fixture base J3289-20 to hold
automatic transmission.
Previously released.
Unique
