7C-50  CLUTCH

5.  OIL LEAKAGE



Checkpoint



Problem



Countermeasure





Replace the body sub

assembly



Weak or damaged piston cup



NG





Tighten the oil pipe





Tighten the oil pipe connection





Tighten the fluid pipe and/or

hose connections





Fluid reservoir





Loosely connected oil pipe





Loosely connected oil pipe





Master cylinder fluid pipe and

hose





Loosely connected fluid pipe

and/or hose





Slave cylinder oil pipe





Replace the piston cup





Slave cylinder





Weak or damaged piston cup



NG

NG

NG

NG

OK

OK

OK

OK



Master cylinder








CLUTCH  7C-51

SPECIAL SERVICE TOOL

ILLUSTRATION

PART NO.

PART NAME







5-8525-3001-0

(J-24547)





Clutch pilot aligner









5-8840-2000-0

(J-5822)





Pilot bearing remover









5-8840-0019-0

(J-23907)





Sliding hammer









5-8840-0125-0

(J-26516-A)





Pilot bearing installer









5-8840-0007-0

(J-8092)





Drive handle






Section 7D Transfer House ............................................................................................ 4879

                                                                     PAGE

Section 7D1 Transfer Control System.......................................................................... 4923

SECTION 7

TRANSFER CASE

TABLE OF CONTENTS

TRANSMISSION

TRANSFER CASE  7D-1

SECTION 7D

TRANSFER CASE

TABLE OF CONTENTS



PAGE

Service Precaution  .........................................................................................................   7D –  2

General Description ........................................................................................................   7D –  3

On-Vehicle Service  .........................................................................................................   7D –  4

Transfer Case Oil Level  ...............................................................................................   7D –  4

Transfer Case Oil Change  ...........................................................................................   7D –  5

Transfer Case Front Oil Seal  ......................................................................................   7D –  6

Transfer Case Rear Oil Seal ........................................................................................   7D –  9

Transfer Case Assembly  ................................................................................................   7D –  11

Transfer Case Assembly and Associated Parts ........................................................   7D –  11

Removal ........................................................................................................................  7D –  12

Installation ....................................................................................................................  7D –  12

Transfer Control Unit ......................................................................................................   7D –  16

Removal ........................................................................................................................  7D –  17

Installation ....................................................................................................................  7D –  17

Transfer Disassembly  ....................................................................................................   7D –  18

Removal ........................................................................................................................  7D –  18

Inspection and Repair  .................................................................................................   7D –  27

Inspection and Repair (Transfer Case Assembly)  ....................................................   7D –  27

Reassembly ..................................................................................................................  7D –  31

Main Data and Specifications  ........................................................................................   7D –  41

Special Tools ................................................................................................................   7D –  44
