Infiniti QX56 (JA60). Manual - part 730
PG
BATTERY
PG-7
< BASIC INSPECTION >
C
D
E
F
G
H
I
J
K
L
B
A
O
P
N
CHARGING THE BATTERY
CAUTION:
• Never “quick charge” a fully discharged battery.
• Keep the battery away from open flame while it is being charged.
• When connecting the charger, connect the leads first, then turn on the charger. Never turn on the
charger first, as this may cause a spark.
• If battery electrolyte temperature rises above 55
°C (131 °F), stop charging. Always charge battery at
a temperature below 55
°C (131 °F).
Charging Rates
Do not charge at more than 50 ampere rate.
NOTE:
The ammeter reading on your battery charger will automatically decrease as the battery charges. This indi-
cates that the voltage of the battery is increasing normally as the state of charge improves. The charging amps
indicated above refer to initial charge rate.
• If, after charging, the specific gravity of any two cells varies more than 0.050, the battery should be replaced.
Work Flow
INFOID:0000000005146574
TROUBLE DIAGNOSIS WITH MULTITASKING BATTERY DIAGNOSTIC STATION
Refer to diagnostic station instruction manual.
−12 (10)
−0.028
−18 (0)
−0.032
Battery electrolyte temperature [
°C (°F)]
Add to specific gravity reading
Corrected specific gravity
Approximate charge condition
1.260 - 1.280
Fully charged
1.230 - 1.250
3/4 charged
1.200 - 1.220
1/2 charged
1.170 - 1.190
1/4 charged
1.140 - 1.160
Almost discharged
1.110 - 1.130
Completely discharged
Amps
Time
50
1 hour
25
2 hours
10
5 hours
5
10 hours
