PERFORMANCE TEST HA-25 < BASIC INSPECTION > C D E F G H J K L M A B HA N O P PERFORMANCE TEST Inspection INFOID:0000000006276158 INSPECTION PROCEDURE 1. Connect recovery/recycling/recharging equipment (for HFC-134a) or manifold gauge. 2. Start the engine, and set to the following condition. Test condition 3. Maintain test condition until A/C system becomes stable. (Approximately 10 minutes) 4. Check that test results of “recirculating-to-discharge air temperature” and “ambient air temperature-to- 5. When test results are within the specified value, inspection is complete. . RECIRCULATING-TO-DISCHARGE AIR TEMPERATURE TABLE FRONT REAR Surrounding condition Indoors or in the shade (in a well-ventilated place) Vehicle condition Door Closed Door glass Full open Hood Open Engine speed Idle speed A/C condition (front/rear) Temperature control switch or dial Full cold A/C switch ON Air outlet VENT (ventilation) Intake door position Recirculation Fan speed Maximum speed set Inside air (Recirculating air) at blower assembly inlet Discharge air temperature from center ventilator ° C ( ° F) Relative humidity % Air temperature ° C ( ° F) 50 – 60 20 (68) 6.8 - 8.8 (44 - 48) 25 (77) 10.4 - 12.9 (51 - 55) 30 (86) 13.9 - 16.9 (57 - 63) 35 (95) 17.3 - 20.8 (63 - 70) 60 – 70 20 (68) 8.8 - 10.8 (48 - 52) 25 (77) 12.9 - 15.4 (55 - 60) 30 (86) 16.9 - 19.9 (63 - 68) 35 (95) 20.8 - 24.3 (70 - 76) Inside air (Recirculating air) at blower assembly inlet Discharge air temperature from rear ventilator grille A RH* ° C ( ° F) Relative humidity % Air temperature ° C ( ° F) 50 – 60 20 (68) 11.4 - 13.4 (53 - 56) 25 (77) 15.8 - 18.3 (60 - 65) 30 (86) 20.9 - 23.9 (70 - 75) 35 (95) 25.9 - 29.4 (79 - 85) |
