IVMS (LAN)
LAN-7
[LAN]
C
D
E
F
G
H
I
J
L
M
A
B
LAN
DIAGNOSTIC ITEMS APPLICATION
X: Applicable
For diagnostic item in each control system, read the CONSULT-ll Operation Manual.
On Board Diagnosis
AKS002M8
ON BOARD DIAGNOSTIC RESULTS INDICATOR LAMP
●
Front map lamps and step lamps (all seats) act as the indicators for the on board diagnosis.
DIAGNOSIS ITEM
Test item
Diagnosed system
MODE
IVMS
COMM
DIAGNO-
SIS
WAKE-UP
DIAGNO-
SIS
SELF
DIAGNOS-
TIC
RESULTS
DATA
MONITOR
ACTIVE
TEST
WORK
SUPPORT
IVMS-COMM CHECK
IVMS communica-
tion and wake-up
function
×
×
DOOR LOCK
Power door lock sys-
tem
×
×
×
AUTO DRIVE POSI-
TIONER
Automatic drive posi-
tioner / Reverse inter-
lock door mirror
system
×
×
×
×
WIPER
Front wiper and
washer system
×
×
×
REAR DEFOGGER
Rear window defog-
ger
×
×
IGN KEY WARN ALM
Warning chime
×
×
LIGHT WARN ALM
Warning chime
×
×
SEAT BELT TIMER
Warning chime
×
×
THEFT WARNING SYS-
TEM
Vehicle security
(Theft warning) sys-
tem
×
×
×
STEP LAMP
Step lamps
×
×
MULTI-REMOTE CONT-
SYS
Remote keyless entry
system
×
×
×
INTERIOR ILLUMINA-
TION
Interior room lamp
×
×
×
SUNROOF RELAY
Sunroof
×
×
DOOR OPEN WARNING
Warning chime
×
×
AUTO LIGHT SYSTEM
Headlamp
×
×
×
Diagnosis item
Content
IVMS communication diagnosis
Diagnosis any error or inability of communication between BCM and LCUs.
Switch monitor
Monitoring conditions of switches connected to BCM, LCUs and door control units.
Power door lock system self-diagnosis
Diagnose malfunctions in the each door lock actuator system.
Auto drive positioner self-diagnosis
Diagnose malfunctions in the each motor and sensor in the electrical load parts of the
driver power seat system (sliding, reclining, and lifter [front/rear]), of the steering wheel
system (tilt, telescoping), and of door mirror.
