DTC P1752 INPUT CLUTCH SOLENOID VALVE AT-147 D E F G H I J K L M A B AT DTC P1752 INPUT CLUTCH SOLENOID VALVE PFP:31940 Description NCS001N5 Input clutch solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehicle CONSULT-II Reference Value NCS001N6 On Board Diagnosis Logic NCS001N7 ● This is an OBD-II self-diagnostic item. ● Diagnostic trouble code “P1752 I/C SOLENOID/CIRC” with CONSULT-II or 5th judgement flicker without – When TCM detects an improper voltage drop when it tries to operate the solenoid valve. – When TCM detects as irregular by comparing target value with monitor value. Possible Cause NCS001N8 ● Harness or connectors ● Input clutch solenoid valve DTC Confirmation Procedure NCS001N9 CAUTION: Always drive vehicle at a safe speed. WITH CONSULT-II 1. Turn ignition switch ON. 2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode 3. Touch “START”. 4. Start engine. 5. Drive vehicle and maintain the following conditions for at least 5 Þ “4” (I/C ON/OFF) Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving 6. If DTC is detected go to AT-148, "Diagnostic Procedure" WITH GST Follow the procedure “WITH CONSULT-II”. Item name Condition Display value (Approx.) I/C SOLENOID Input clutch disengaged. Refer to . 0.6 - 0.8 A Input clutch engaged. Refer to 0 - 0.05 A BCIA0030E |
