Terminals and Reference Value for Audio Unit for Base System

NKS002F3

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

–

Ignition

switch

Operation

2

(L)

1

(B/W)

Audio signal front
LH

Output

ON

Receive audio sig-
nal

4

(BR)

3

(B/R)

Audio signal front
RH

Output

ON

Receive audio sig-
nal

5

(R/W)

Ground

Antenna signal

Output

ON

—

Approx. 12 V

6

(Y)

Ground

Battery power
supply

Input

OFF

—

Battery voltage

10

(LG)

Ground

ACC power sup-
ply

Input

ACC

—

Battery voltage

14

(LG)

13

(B/Y)

Audio signal rear
LH

Output

ON

Receive audio sig-
nal

16

(OR)

15

(B/P)

Audio signal rear
RH

Output

ON

Receive audio sig-
nal

18

(W/G)

Ground

Vehicle speed
signal (2-pulse)

Input

ON

When vehicle speed
is approx. 40 km/h
(25 MPH)

22

(R)

Ground

Remote control A

Input

ON

Press MODE
switch

Approx. 0 V

Press SEEK UP
switch

Approx. 1.7 V

Press VOL UP
switch

Approx. 3.3 V

Except for above

Approx. 5 V

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

ELF1080D

AV-22

AUDIO

Terminals and Reference Value for Audio Unit for BOSE System

NKS002F4

23

(G)

Ground

Remote control B

Input

ON

Press POWER
switch

Approx. 0 V

Press SEEK DOWN
switch

Approx. 1.7 V

Press VOL DOWN
switch

Approx. 3.3 V

Except for above

Approx. 5 V

24

(R/B)

Ground

Voice guidance
ON signal (With
navigation sys-
tem)

Input

ON

Press the “VOICE”
switch

25

(Y)

—

Remote control
ground

—

ON

—

Approx. 0 V

31

(B)

—

Shield (With navi-
gation system)

—

—

—

—

32

(L/W)

30

(W/B)

Voice guidance
signal (With navi-
gation system)

Input

ON

When inputting
voice guidance

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

–

Ignition

switch

Operation

SKIB0232E

SKIB3609E

Terminal

 (Wire color)

Item

Signal

input/out-

put

Condition

Reference value

+

–

Ignition

switch

Operation

2

(W)

1

(B)

Audio signal front
LH

Output

ON

Receive audio sig-
nal

4

(G)

3

(R)

Audio signal front
RH

Output

ON

Receive audio sig-
nal

5

(G/W)

Ground

Antenna signal

Output

ON

—

Approx. 12 V

6

(Y)

Ground

Battery power
supply

Input

OFF

—

Battery voltage

9

—

Shield

—

—

—

—
