VEHICLE SECURITY (THEFT WARNING) SYSTEM

BL-171

< SERVICE INFORMATION >

C

D

E

F

G

H

J

K

L

M

A

B

BL

N

O

P

TIWM1676E

BL-172

< SERVICE INFORMATION >

VEHICLE SECURITY (THEFT WARNING) SYSTEM

TIWM0551E

VEHICLE SECURITY (THEFT WARNING) SYSTEM

BL-173

< SERVICE INFORMATION >

C

D

E

F

G

H

J

K

L

M

A

B

BL

N

O

P

Terminal and Reference Value for BCM

INFOID:0000000001327910

Terminal Wire color

Item

Signal

Input/

output

Condition

Voltage (V)

(Approx.)

11

LG

ACC power supply
(ACC or ON)

Input

Ignition switch (ACC or ON po-
sition)

Battery voltage

12

P/B

Front door switch
passenger side signal

Input

ON (Open)

→

 OFF (Closed)

0

→

 Battery voltage

13

P/L

Rear door (RH) switch sig-
nal

Input

ON (Open)

→

 OFF (Closed)

0

→

 Battery voltage

18

B

Remote keyless entry re-
ceiver (Ground)

—

—

0

19

R

Remote keyless entry re-
ceiver (Power supply)

Output

—

20

Y

Remote keyless entry re-
ceiver (Signal)

Input

Stand-by

When remote keyless entry re-
ceiver receives signal from
keyfob.

22

OR

Power window serial link

Input/

Output

IGN SW ON or power window
timer operating

23

G/OR

Security indicator lamp

Output

Goes off

→

 Illuminates

Battery voltage

→

 0

39

L

CAN-H

Input/

Output

—

—

40

P

CAN-L

Input/

Output

—

—

42

L/R

Power source (Fuse)

Input

—

Battery voltage

49

B

Ground (signal)

—

—

0

52

B

Ground (power)

—

—

0

55

G

Power source (Fusible link)

Input

—

Battery voltage

58

L

Back door switch signal

Input

ON (Open)

→

 OFF (Closed)

0

→

 9

OCC3881D

OCC3879D

OCC3880D

PIIA2344J

BL-174

< SERVICE INFORMATION >

VEHICLE SECURITY (THEFT WARNING) SYSTEM

Terminal and Reference Value for IPDM E/R

INFOID:0000000001327911

CONSULT-III Function

INFOID:0000000001327912

WORK SUPPORT

DATA MONITOR

62

W

Front door switch
driver side signal

Input

ON (Open)

→

 OFF (Closed)

0

→

 Battery voltage

63

P

Rear door (LH) switch sig-
nal

Input

ON (Open)

→

 OFF (Closed)

0

→

 Battery voltage

Terminal Wire

color

Item

Signal

Input/

output

Condition

Voltage (V)

(Approx.)

Terminal Wire

color

Item

Signal

Input/

output

Condition

Voltage (V)

(Approx.)

20

LG

Headlamp low (RH)

Output

Lighting switch 2ND position
ON

→

 OFF

Battery voltage

→

 0

27

BR

Headlamp high (RH)

Output

Lighting switch HIGH or PASS
position
ON

→

 OFF

Battery voltage

→

 0

28

SB

Headlamp high (LH)

Output

Lighting switch HIGH or PASS
position
ON

→

 OFF

Battery voltage

→

 0

30

GY

Headlamp low (LH)

Output

Lighting switch 2ND position
ON

→

 OFF

Battery voltage

→

 0

38

B

Ground (power)

—

—

0

48

L

CAN-H

Input/

Output

—

—

49

R

CAN-L

Input/

Output

—

—

51

SB

Horn relay control signal

Output

Panic alarm is operating

0

Other than above

Battery voltage

56

LG

Hood switch signal

Input

ON (Open)

→

 OFF (closed)

0

→

 Battery voltage

60

B

Ground (signal)

—

—

0

BCM diagnosis

test item

Check item diagnosis test mode

Content

Theft alm

WORK SUPPORT

Change setting of each function.

DATA MONITOR

Displays the input data of BCM real time.

ACTIVE TEST

Gives a drive signal to a load to check the operation.

Test Item

Description

SECURITY ALARM SET

This mode is able to confirm and change security alarm ON-OFF setting.

THEFT ALM TRG

The switch which triggered vehicle security alarm is recorded. This mode is able to confirm and
erase the record of vehicle security alarm. The trigger data can be erased by touching “CLEAR” on
CONSULT-III screen.
