BR-10 < ON-VEHICLE MAINTENANCE > BRAKE FLUID BRAKE FLUID Inspection INFOID:0000000003139969 BRAKE FLUID LEVEL • Check that the fluid level in the reservoir tank is within the specified range (MAX – MIN lines). • Visually check for any brake fluid leakage around the reservoir tank. • Check the brake system for any leakage if the fluid level is extremely low (lower than MIN). • Check the brake system for fluid leakage if the warning lamp remains illuminated even after the parking brake is released. BRAKE LINE 1. Check brake line (tubes and hoses) for cracks, deterioration or other damage. Replace any damaged 2. Check for fluid leakage by fully depressing brake pedal while CAUTION: If leakage occurs around joints, retighten or, if necessary, Draining INFOID:0000000003139970 CAUTION: • Never spill or splash brake fluid on painted surfaces. Brake fluid may seriously damage paint. Wipe it off immediately and wash with water if it gets on a painted surface. • Turn the ignition switch OFF and disconnect the ABS actuator and electric unit (control unit) con- nector or the battery negative terminal before performing work. 1. Connect a vinyl tube to the bleed valve. 2. Depress the brake pedal and loosen the bleeder valve to gradu- Refilling INFOID:0000000003139971 CAUTION: Turn the ignition switch OFF and disconnect the ABS actuator and electric unit (control unit) connec- 1. Check that there is no foreign material in the reservoir tank, and refill with new brake fluid. CAUTION: Never reuse drained brake fluid. JPFIA0007ZZ SBR389C BRA0007D |
