WCS UNIFIED METER AND A/C AMP. WCS-47 < ECU DIAGNOSIS > C D E F G H I J K L M B A O P PHYSICAL VALUES JSNIA0097ZZ Terminal No. (Wire color) Description Condition Value (Approx.) + – Signal name Input/ Output 5 (L) Ground Manual mode shift up sig- Input Ignition Selector lever UP operation 0 V Other than the above 12 V 7 (GR) Ground Communication signal → METER) Output Ignition — 8 (L) Ground Vehicle speed signal output Output Ignition Speedometer operated NOTE: 9 (SB) Ground Seat belt buckle switch sig- Input Ignition When seat belt is fastened 12 V When seat belt is not fas- 0 V 10 (W) Ground Manual mode signal Input Ignition Selector lever DS position 0 V Other than the above 12 V 11 (G) Ground Not manual mode signal Input Ignition Selector lever DS position 12 V Other than the above 0 V 14 (BR) Ground Communication signal → AMP.) Input Ignition — SKIA3362E JSNIA0015GB JSNIA0028GB |
