62

BODY DIMENSIONS - Interior

Roof bow mounting
(

∅

9.8) (Long body)

K

Head lining mounting hole
(

∅

8.5)

M

DIBD0160

DIBD0140

Roof bow mounting
(

∅

9.8) (Long body)

L

DIBD0150

Í

Í

Í

Í

Í

Ó

Ó

Ó

Ó

Ó

Ô

Ô

Ô

Ô

Ô

63

BODY DIMENSIONS - Front body

Point symbol

Length (mm)

A-A'

1400

A-B

366

A-B'

1490

B-B'

1490

D-D'

688

E-E'

872

F-F'

940

C-C'

676

G-G'

872

I-I'

1492

J-J'

1556

H-H'

1450

* These dimensions indicated in this figure are actual-measurement dimensions.

J-I'

1333

I-J

415

Point symbol

Length (mm)

FRONT BODY

DIAE0010

J

I

D

E

G

C

J'

D'

F'

E'

G'

C'

A'

I'

A

B'

B

H

H'

F

64

Front bumper upper rail
mounting (

∅

7)

Location hole (2WD)
(

∅

8)

Shock absorer mounting (2WD)
(

∅

15)

Location hole (4WD)
(

∅

12)

Wheel guard mounting hole
(…9)

A

B

C

BODY DIMENSIONS - Front body

D

E

G

H

F

I

J

Thermo sensor mounting
(

∅

7)

Head lamp mounting
(

∅

7)

Location hole
(

∅

10)

Fender mounting hole
(

∅

10.5)

Fender mounting hole
(

∅

6.6)

Í

Í

Í

Í

Í

DIAE0020

Í

Í

Í

Í

Í

DIAE0030

Ô

Ô

Ô

Ô

Ô

DIAE0040

Ó

Ó

Ó

Ó

Ó

DIAE0070

DIAE0060

Ò

Ò

Ò

Ò

Ò

DIAE0050

Í

Í

Í

Í

Í

DIAE0080

Ô

Ô

Ô

Ô

Ô

DIAE0090

Î

Î

Î

Î

Î

Ó

Ó

Ó

Ó

Ó

DIAE0100

Í

Í

Í

Í

Í

DIAE0110

65

BODY DIMENSIONS -Rear body

Point symbol

Length (mm)

A-A'

1379

A-B

670

A-C'

1782

A-D

1405

B-B'

1596

B-D

977

B'-C'

465

B-A'

1628

C-B'

1565

C-C'

1400

* These dimensions indicated in this figure are actual-measurement dimensions.

Point symbol

Length (mm)

DIAF0010

REAR BODY

B

A

C

D

C'

B'

A'
