2-32. FUEL INJECTION PUMP REPAIR (Cont’d) 60. Remove terminal (2), washer (3), and shell (4) from stud (9). 61. Remove nut (5), lockwasher (6), washer (7), and fiber washer (8) from stud (9). Discard lockwasher (6). washer (8) from stud (11). Discard locknut (14) and lockwashers (6). 63. Remove electrical shutoff solenoid (10) from cover (12). 2-96 |
