Is DTC P0365 indicated?

YES -Go to step 5.

NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at
CMP sensor B and the ECM/PCM.

5. Turn the ignition switch OFF.

6. Disconnect CMP sensor B 3P connector.

7. Turn the ignition switch ON (II).

8. Measure voltage between CMP sensor B 3P connector terminal No. 3 and body ground.

Fig. 74: Measuring Voltage Between CMP Sensor B 3P Connector Terminal No. 3 And Body
Ground
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Is there battery voltage?

YES -Go to step 9.

NO -Repair open in the wire between the CMP sensor B and PGM-FI main relay 1 (FI MAIN), then go to
step 19.

9. Measure voltage between CMP sensor B 3P connector terminal No. 1 and body ground.



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE PGM-FI System - Element



Fig. 75: Measuring Voltage Between CMP Sensor B 3P Connector Terminal No. 1 And Body
Ground
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Is there about 5 V?

YES -Go to step 10.

NO -Go to step 11.

10. Measure voltage between CMP sensor B 3P connector terminals No. 2 and No. 3.

Fig. 76: Measuring Voltage Between CMP Sensor B 3P Connector Terminals No. 2 And No. 3
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Is there battery voltage?

YES -Go to step 17.

NO -Repair open in the wire between the CMP sensor B and G101, then go to step 19.

11. Turn the ignition switch OFF.

12. Jump the SCS line with the HDS.

13. Disconnect ECM/PCM connector A (31P).

14. Check for continuity between ECM/PCM connector terminal A6 and body ground.



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE PGM-FI System - Element



Fig. 77: Checking Continuity Between ECM/PCM Connector Terminal A6 And Body Ground
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Is there continuity?

YES -Repair short in the wire between the ECM/PCM (A6) and the CMP sensor B, then go to step 19.

NO -Go to step 15.

15. Connect CMP sensor B 3P connector terminal No. 1 to body ground with jumper wire.

Fig. 78: Connecting CMP Sensor B 3P Connector Terminal No. 1 To Body Ground With Jumper
Wire
Courtesy of AMERICAN HONDA MOTOR CO., INC.

16. Check for continuity between ECM/PCM connector terminal A6 and body ground.



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE PGM-FI System - Element



Fig. 79: Checking Continuity Between ECM/PCM Connector Terminal A6 And Body Ground
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Is there continuity?

YES -Go to step 25.

NO - Repair open in the wire between the ECM/PCM (A6) and the CMP sensor B, then go to step 19.

17. Turn the ignition switch OFF.

18. Replace the CMP sensor B (see CMP SENSOR B REPLACEMENT ).

19. Reconnect all connectors.

20. Turn the ignition switch ON (II).

21. Reset the ECM/PCM with the HDS.

22. Do the ECM/PCM idle learn procedure (see ECM/PCM IDLE LEARN PROCEDURE ).

23. Check for Temporary DTCs or DTCs with the HDS.

Is DTC P0365 indicated?

YES -Check for poor connections or loose terminals at the CMP sensor B and the ECM/PCM, then go to
step 1.

NO -Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the
INDICATED DTCS TROUBLESHOOTING.

24. Reconnect all connectors.

25. Update the ECM/PCM if it does not have the latest software (see UPDATING THE ECM/PCM ), or

substitute a known-good ECM/PCM (see SUBSTITUTING THE ECM/PCM ).

26. Check for Temporary DTCs or DTCs with the HDS.

Is DTC P0365 indicated?

YES -Check for poor connections or loose terminals at the CMP sensor B and the ECM/PCM. If the
ECM/PCM was updated, substitute a known-good ECM/PCM (see SUBSTITUTING THE



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE PGM-FI System - Element
