YES -Repair short in the wire between the throttle body and the throttle actuator control module (TPSB NO -Substitute a known-good throttle actuator control module (see THROTTLE ACTUATOR 9. Measure voltage between throttle body 6P connector terminal No. 2 and body ground. Fig. 12: Measuring Voltage Between Throttle Body 6P Connector Terminal No. 2 And Body Is there about 5 V? YES -Go to step 15. NO -Go to step 10. 10. Turn the ignition switch OFF. 11. Disconnect the throttle actuator control module 16P connector (see THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT ). 12. Disconnect the throttle body 6P connector. 13. Connect throttle body 6P connector terminal No. 2 to body ground with a jumper wire.
2007 Honda Element EX 2007-2008 ENGINE PERFORMANCE Electronic Throttle Control System - Element
|
