Honda Element. Manual - part 405

Fig. 10: Disconnecting Power Window Switch Connector And Power Mirror Switch
Connector With Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

11. Install the door panel in the reverse order of removal, and note these items:



Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.



Make sure the connectors are plugged in properly, and the rod is connected properly.



Push the clips portion into place securely.



Do the power window control unit reset procedure (see RESETTING THE POWER WINDOW
CONTROL UNIT ).



Check the window and power door lock operations.



When reinstalling the door panel, make sure the plastic cover is installed properly and sealed
around its perimeter to seal out water.



Check for water leaks (see step 7 ).

FRONT DOOR OUTER HANDLE REPLACEMENT

1. Remove these items:



Door panel (see FRONT DOOR PANEL REMOVAL/INSTALLATION )



Plastic cover, as necessary (see COMPONENT LOCATION INDEX - FRONT DOOR )

2. Raise the glass fully.

3. Pull the glass run channel (A) away as necessary, and remove the bolt, then remove the center lower

channel (B) by pulling it downward.

NOTE:

Put on gloves to protect your hands.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Doors - Element



Fig. 11: Removing Center Lower Channel With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Remove the access seal (A), and disconnect the outer handle rod (B) from the bushing (C) and cylinder

rod (D).

Fig. 12: Disconnecting Outer Handle Rod From Bushing And Cylinder Rod
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Push the top of the retainer clip (A) with a flat-tip screwdriver (B), and hold it. Release the retainer clip

NOTE:

Check the bushing for damage and replace if necessary.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Doors - Element



with a hook-shaped tool (C), then remove the lock cylinder (D).

Fig. 13: Pushing Top Of Retainer Clip With Flat-Tip Screwdriver
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Remove the bolts, then remove the outer handle protector (A).

Fig. 14: Removing Outer Handle Protector With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Release the hooks (A), then remove the outer handle (B). Take care not to scratch the door.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Doors - Element



Fig. 15: Removing Outer Handle
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Install the outer handle in the reverse order of removal, and note these items:



Make sure each rod is connected securely.



Make sure the door locks and opens properly.



When installing the lock cylinder, leave the outer door handle bolts loose so the inner protector
does not interfere with the lock cylinder installation, then tighten the handle bolts.



Install the lock cylinder retaining clip on the handle, then install the lock cylinder. Be sure the clip
is fully seated in the slot on the lock cylinder.



When reinstalling the door panel, make sure the plastic cover is installed properly and sealed
around its perimeter to seal out water.



Check for water leaks.

FRONT DOOR LATCH REPLACEMENT

1. Remove these items:



Door panel (see FRONT DOOR PANEL REMOVAL/INSTALLATION )



Plastic cover, as necessary (see COMPONENT LOCATION INDEX - FRONT DOOR )

2. Raise the glass fully.

3. Remove the center lower channel (see step 3 ).

4. Remove the access seal, and disconnect the outer handle rod and cylinder rod (see step 4 ).

5. To ease reassembly, note the distance (A) of the lock rod (B) on the lock knob (C) before disconnecting

it.

NOTE:

Put on gloves to protect your hands.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Doors - Element
