1. Remove the snap ring with a screwdriver.

Fig. 476: Removing Snap Ring With Screwdriver
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the clutch end-plate (A), clutch discs (B) (5), clutch wave-plates (C) (4), clutch flat-plate (D) and

waved spring (E) from the 1st clutch drum (F).

Fig. 477: Disassembled View Of 1st Clutch Drum
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Make reference mark on the clutch flat-plate.

4. Remove the clutch end-plate (A), clutch discs (B) (6), clutch wave-plates (C) (5), flat-plate (D), and

waved spring (E) from the 2nd clutch drum (F).



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 478: Disassembled View Of 2nd Clutch Drum
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Make a reference mark on the flat-plate.

6. Remove the clutch end-plate (A), clutch discs (B) (6), clutch wave-plates (C) (5), clutch flat-plate (D),

and waved spring (E) from the 3rd clutch drum (F).

Fig. 479: Disassembled View Of 3rd Clutch Drum
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Make reference marks on the clutch flat-plate.

8. Remove the clutch end-plate (A), clutch discs (B) (4), clutch wave-plates (C) (4), and waved spring (D)

from the 4th clutch drum (E).



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 480: Disassembled View Of 4th Clutch Drum
Courtesy of AMERICAN HONDA MOTOR CO., INC.

9. Remove the clutch end-plate (A), clutch discs (B) (4), clutch wave-plates (C) (4), and waved spring (D)

from the 5th clutch drum (E).

Fig. 481: Disassembled View Of 5th Clutch Drum
Courtesy of AMERICAN HONDA MOTOR CO., INC.

10. Install the clutch spring compressor attachment and clutch spring compressor bolt assembly.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 482: Identifying Clutch Spring Compressor Attachment And Clutch Spring Compressor Bolt
Assembly
Courtesy of AMERICAN HONDA MOTOR CO., INC.

11. Be sure the clutch spring compressor attachment (A) is adjusted to have full contact with the spring

retainer (B) on the 4th and 5th clutches.

Fig. 483: Contacting With Spring Retainer On 4th And 5th Clutches
Courtesy of AMERICAN HONDA MOTOR CO., INC.

12. Set the clutch spring compressor attachment (A) on the spring retainer (B) of the 1st, 2nd, and 3rd

clutches in such a way that the clutch spring compressor attachment works on the clutch return spring (C).
