shift cable end and shift cable end holder. Do not pry the shift cable lock with a screwdriver, it may
damage the shift cable end holder.

6. Separate the shift cable end (A) from the shift cable end holder (B).

Fig. 320: Identifying Shift Cable And Shift Cable Holder
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Rotate the socket holder (A) on the shift cable (B) a quarter turn; the tab (C) on the socket holder will be

in the opening (D) of the shift cable bracket (E). Then slide the holder to remove the shift cable from the
shift cable bracket. Do not remove the shift cable by twisting shift cable guide (F) and damper (G).

Fig. 321: Rotating Socket Holder On Shift Cable
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Push the shift cable down until it stops, then release it. Pull the shift cable back one step so that the shift

cable is in R. Do not hold the shift cable guide (A) to adjust the shift cable (B).



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 322: Pushing Shift Cable Down Until
Courtesy of AMERICAN HONDA MOTOR CO., INC.

9. Turn the ignition switch ON (II), and check that the R position indicator comes on.

10. Turn the ignition switch OFF.

11. Insert a 6.0 mm (0.24 in.) pin (A) into the positioning hole (B) on the shift lever bracket through the

positioning hole on the shift lever. The shift lever is secured in the R position.

Fig. 323: Inserting Pin Into Positioning Hole On Shift Lever Bracket
Courtesy of AMERICAN HONDA MOTOR CO., INC.

12. Rotate the socket holder (A) on the shift cable (B) to face the tab (C) on the holder opposite the opening

(D) in the shift cable bracket (E). Align the holder with the opening in the bracket, then slide the holder
into the bracket. Rotate the holder a quarter turn to secure the shift cable. Do not install the shift cable by
twisting the shift cable guide (F) and damper (G).



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 324: Rotating Socket Holder On Shift Cable
Courtesy of AMERICAN HONDA MOTOR CO., INC.

13. Install the shift cable end (A) in the shift cable end holder (B). Keep the shift cable end and end holder

free of grease.

Fig. 325: Identifying Shift Cable And Holder
Courtesy of AMERICAN HONDA MOTOR CO., INC.

14. Install the new shift cable lock (A) to secure the shift cable end and shift cable end holder, then push the

lock tab (B) up until it stops to lock joint.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 326: Pushing Lock Tab
Courtesy of AMERICAN HONDA MOTOR CO., INC.

15. Remove the 6.0 mm (0.24 in.) pin that was installed to hold the shift lever.

16. Install the shift cable insulator (A) along the slot (B) over the shift cable (C), and position the shift cable

in the left end (D) of the slot.

Fig. 327: Identifying Shift Cable Insulator
Courtesy of AMERICAN HONDA MOTOR CO., INC.

17. Push the insulator down so that it covers the shift cable grommet(E).

18. Allow the all four wheels (4WD) or the front wheels (2WD) to rotate freely.

19. Start the engine, and move the shift lever to each position. Check that the A/T gear position indicator

follows the transmission range switch, and check the shift lever operation in each gear.

20. Install the center lower cover (see CENTER LOWER COVER REMOVAL/INSTALLATION ).
