7. To remove a front drain valve (A) from the body, remove the kick panel, left or right (see FRONT DOOR SILL AREA - 4-DOOR ), and the driver's Detach the clips (B), then remove the front drain tube (C). Fig. 26: Removing Front Drain Valve From Body 8. To remove a rear drain valve (A) from the body, remove these parts: Spare tire lid (see step 2 in TRIM REMOVAL/INSTALLATION - Trunk rear trim panel (see step 5 in TRIM Trunk side trim panel (see step 6 in TRIM Tie a string to the top end of the rear drain tube (B), then pull the drain tube
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Moonroof - Civic
|
