Fig. 44: Aligning Ledge Portion 2. Compress the damper spring. onto the damper unit (A) by referring to the Exploded View. Fig. 45: Exploded View Of Damper 4. Align the bottom of the spring (B) and the stepped part of the lower spring seat (C). 5. Align the damper bracket (A) and the damper mounting base (B) so that the "delta" stamp (C) points toward the front. Fig. 46: Aligning Angle Of Strut Bolt On Damper Bracket 6. Align the angle of the strut bolt (D) on the damper bracket as shown.
2008 Honda Civic GX 2006-08 SUSPENSION Front Suspension Civic (All Except Hybrid)
|
