245










246



No. 178 Braking with abnormal sound

Malfunction

Causes

Solution

Fixed screws for suspension connection of
brake system loosening or damaged;

Check fixed screws for suspension connection of brake
system are loosening or damaged; if so, fasten or replace;

Fixed bolt of front brake tongs loosening or with
worn lining;

Fasten or replace front brake tongs assembly;

Vacuum booster internally damaged;

Check vacuum booster is internally damaged; if so,
replace it;

Brake disk severely worn;

Check brake disk is severely worn; if so, replace it;

Material of brake disk too hard;

Check material of brake disk is too hard; if so, grind or
replace it;

Brake hub or disk severely worn with groove;    Replace brake hub or disk;

Braking with
abnormal sound
while vehicle is
driving normally

Rubber cover of front and rear suspensions
loosening, aging;

Replace rubber cover of front and rear suspensions;










247



Grind or replace

Replace

Fasten or replace

Check fixed screws for suspension connection of brake system are
loosening or damaged;

Rubber cover of front and rear
suspensions loosening, aging

Vacuum booster internally damaged

Brake disk severely worn

Fixed bolt of front brake tongs loosening or with worn
lining

Brake hub or disk severely worn with
groove

Grind or replace

Replace

Braking with
unusual noise

Material of brake disk too hard

Grind or replace

Replace

Unusual

Abnormal

Abrasion

Abnormal

Abnormal

Abnormal

Abnormal

Normal

Normal

Normal

Normal

Normal

Normal








248



No. 179 Braking sideslipping, swerving

Malfunction

Causes

Solution

Tire worn smoothly

Check tire is worn smoothly; if so, replace it;

Tire of the same axle not consistent

Check tire of the same axle is consistent; if not, adjust it;

Tire pressure too low or too high

Check tire pressure is too low or too high; if so, adjust to specified
pressure;

Brake shoe, brake disk with oil sludge;  Check brake shoe, brake disk are with oil sludge; if so, clean it;

Air in the pipeline;

Check air is in the pipeline; if so, empty it;

Pressure dividing valve incorrectly
adjusted

Check pressure dividing valve is incorrectly adjusted; if so, readjust
it;

While braking,
vehicle slips to one
side or swerves

Rubber cover of chassis suspension
loosening

Check rubber cover of chassis suspension is loosening; if
necessary, replace rubber cover;
