P0302-CYLINDER 2 MISFIRE (CONTINUED) 16. (K17) COIL CONTROL NO.2 CIRCUIT Turn the ignition off. Disconnect the C2 PCM harness connector. CAUTION: Do not probe the PCM harness connectors. Probing Was a problem found with the (K17) Coil Control No.2 circuit? Yes >> Repair the (K17) Coil Control No.2 circuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer No >> Go To 17 17. PCM NOTE: Before continuing, check the PCM harness connector terminals for corrosion, damage, or terminal Were there any problems found? Yes >> Repair as necessary. Perform the POWERTRAIN VERIFICATION TEST. (Refer to 9 - ENGINE - STANDARD PROCEDURE) No >> Replace and program the Powertrain Control Module per Service Information. Perform the POWERTRAIN VERIFICATION TEST. (Refer to 9 - ENGINE - STANDARD PROCEDURE) HB ENGINE ELECTRICAL DIAGNOSTICS 9 - 331 |
