P0308-CYLINDER 8 MISFIRE (CONTINUED) 9. ENGINE MECHANICAL PROBLEM Check for any of the following conditions/mechanical problems. ENGINE VACUUM - must be at least 13 inches in neutral ENGINE VALVE TIMING - must be within specifications ENGINE COMPRESSION - must be within specifications ENGINE EXHAUST SYSTEM - must be free of any restrictions or leaks. ENGINE PCV SYSTEM - must flow freely TORQUE CONVERTER STALL SPEED - must be within specifications POWER BRAKE BOOSTER - no internal vacuum leaks FUEL - must be free of contamination CAM LOBES - must not be worn excessively CYLINDER LEAKAGE TEST - must be within specifications VALVE SPRINGS - cannot be weak or broken Are there any engine mechanical problems? Yes >> Repair as necessary. Perform POWERTRAIN VERIFICATION TEST. (Refer to 9 - ENGINE - STANDARD PROCEDURE) No >> Go To 16 10. FUEL INJECTOR Turn the ignition off. Disconnect the No.8 Fuel Injector harness connector. Ignition on, engine not running. NOTE: When a Misfire is detected for a particular cylinder, the Using a 12-volt test light connected to 12-volts, probe the (K28) Injec- With the scan tool, actuate the Fuel Injector. Does the test light blink/flicker? Yes >> Replace the Fuel Injector. Perform POWERTRAIN VERIFICATION TEST. (Refer to 9 No >> Go To 11 9 - 346 ENGINE ELECTRICAL DIAGNOSTICS ND |
