LAMP 1. Disconnect and isolate the battery negative cable. 2. Using hand pressure, press the rear edge of the license plate lamp lens/housing (5) toward the front 3. Pull the lamp out from the rear bumper far enough to access the bulb socket (3) on the back of the 4. Firmly grasp the socket on the back of the housing and rotate it counterclockwise about 30 degrees to 5. Pull the socket and bulb straight out from the keyed opening in the lamp housing. 6. Remove the lamp from the rear bumper. INSTALLATION BULB CAUTION: Always use the correct bulb size and type for replacement. An incorrect bulb size or type may 1. Align the base of the bulb with the license plate lamp socket (1). 2. Push the bulb straight into the socket until the base is firmly seated. 3. Align the socket and bulb with the keyed opening on the back of the license plate lamp housing (3). 4. Insert the socket and bulb into the housing until the socket is firmly seated. 5. Rotate the socket clockwise about 30 degrees to lock it into place. 6. Reconnect the battery negative cable. 8L - 106 LAMPS/LIGHTING - EXTERIOR - SERVICE INFORMATION ND |
