9U-4  CONTROL UNITS AND SYSTEM

NO.

Application

Deseription

13

Ignition key hole illumination

l

Coupled with door switch, ignition key hole illumination lamp will

turn on when the driver’s door is opened and will dim off after 10

sec. after closing the door.

14

Auto door lock

l

All doors will be locked automatically if the vehicle speed

reaches 50km/h though the doors are in unlock.

15

Auto door unlock

l

All doors will be automatically unlocked if the vehicle crashes

while driving (over 15km/h).

16

Input checking function

l

Self diagnostic function for each sensor switches and loads for

the system.

12

Coupled with REKES

l

Being coupled with REKES (remote keyless entry system), all

doors will be locked/unlocked according to signals of transmitter

when the ignition key is not inserted.

CONTROL UNITS AND SYSTEM  9U-5

Operating Characteristics

1. Wiper INT sensing vehicle speed

T1 : within 0.5 sec.

T2 : Wiper motor 1 revolution time

T3 : 1.5±0.2 sec. - 20±2 sec.

2.  Washer relating wiper

T1 : 0.6 - 1.0 sec.

T2 : motor 3 revolution (including motor revolution time)

3. Dimming room lamp

T1 : 2±0.3 sec.

T2 : 3±0.5 sec

4. Time delayed power window control

T : 30±2 sec

9U-6  CONTROL UNITS AND SYSTEM

5. Rear defogger timer

T1 : 12±2 min.

T2 : within 10±1 min.

T3 : 6±1 min.

6. Seat belt warning timer

T1 : 6±1 sec.

T2 : 0.3±0.1 sec.

T3 : 0.6±0.1 sec.

7. Parking brake warning

T1 : 0.3±0.1 sec.

T2 : 0.3±0.1 sec.

V1 : 3km/h - 5km/h

8. Tail lamp lighting warning

l

When the driver’s door is opened after removing the IGN
key while the tail lamp switch is still ON, the buzzer should
be operated.

T1 : 0.3±0.1 sec.

T2 : 0.3±0.1 sec.

CONTROL UNITS AND SYSTEM  9U-7

l

After 1), the driver’s or passenger’s door should be
unlocked when it locked.

T1 : within 0.2±5 sec.

T2 : 5±0.5 sec.

9. Door ajar warning

T1 : 0.3±0.1 sec.

T2 : 0.3±0.1 sec.

V1 : 3 - 5km/h

10. IGN key reminder warning

T1 : within 0.2 sec.

T2 : 5±0.5 sec.

T3 : 0.3±0.1 sec.

T4 : 0.3±0.1 sec.

T5 : 0.5±0.1 sec.
