9T – 28 IMMOBILIZER ANTI-THEFT SYSTEM DAEWOO M–150 BL2 D29T002 Installation Procedure 1. Install the detection coil by pressing it onto the lock cylinder until it snaps in place. 2. Connect the two-pin connector to the immobilizer. D105A505 3. Install the steering column covers with the screws. Refer to Section 6E, Steering Wheel and Column. D105A504 IMMOBILIZER CONTROL UNIT (Left–Hand Drive Shown, Right–Hand Removal Procedure 1. Disconnect the negative battery cable. 2. Remove the steering column covers. Refer to Section 6E, Steering Wheel and Column. D29T003 3. Slide the immobilizer control unit toward steering wheel until it slides off its mounting bracket. 4. Disconnect the electrical connectors from the immo- bilizer control unit (1). |
