AUTOMATIC TRANSMISSION 5A-91 C3 Clutch Cylinder To remove the C3 clutch cylinder, proceed as follows: 1. Remove the forward sun gear and thrust bearing from the C3 clutch cylinder. 2. Remove the nylon thrust bearing, bearing support, needle thrust bearing and thrust block from the clutch cylinder hub. 3. Mount the clutch assembly on tool No.0555-331899 and compress the piston return spring. Remove the circlip and release the spring. Notice Make sure that the spring keeper has not been caught in 4. Remove the tool, circlip, keeper and spring. 5. Remove the sealing rings from the C3 clutch cylinder. 6. Remove the clutch plate retaining circlip and remove the clutch plates. 7. To remove the clutch piston from the clutch cylinder, apply air pressure to the port between the iron sealing rings on 8. Remove the reverse sun gear from the cylinder. |
