1F1-42 M162 ENGINE CONTROLS Pin No. 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 Description Injector-cylinder 2 Injector-cylinder 4 Injector-cylinder 1 Injector-cylinder 6 Injector-cylinder 5 Injector-cylinder 3 E-GAS motor plus E-GAS motor minus Power ground TM.31 Ignition coil cylinder 1+6 Ignition coil cylinder 2+5 Ignition coil cylinder 3+4 Camshaft control - - - - Engine coolant temperature Temperature ground Intake air temperature Hot film air mass signal - - E-GAS potentiometer ground E-GAS potentiometer 2 signal - E-GAS potentiometer 1 signal - - - EV5 EV6 EV1 EV4 EV2 EV3 M+ M- TM.31 ZSC16 ZSA25 ZSB34 NWS - - - - MT GND LT HFM - - GND IP2S - IP1S - - - l - - - - l - - l - l - - - l - - - - l - - l - l - - - Remarks Abbreviation E32 ENG, 5speed M/T E32 ENG, 4speed A/T (BTRA) |
