OM600 ENGINE COOLING 1D3-7 Removal & Installation Procedure 1. Loose the bolts(5) and remove the pulley (4). Installation Notice Tightening Torque 10 Nm 2. Loose the bolts (3). Installation Notice Tightening Torque 10 Nm 3. Pull the tensioning lever(1) to the arrow direction. 4. Remove the coolant pump(6). Notice Clean gasket residues on the sealing surface of coolant 5. Installation should follow the removal procedure in the reverse order. |
