GENERAL ENGINE INFORMATION 1A2-9 ENGINE CRANKING AT THE FRONT OF CRANKSHAFT Preceding Work : Removal of cooling fan 1 Vibration Damper Assembly Notice l Remove the negative ground cable before proceeding the work. l Rotate the pulley in normal engine rotating direction when cranking. 3 Bolt ................................................. 8.6 ± 0.9 Nm Tools Required 000 589 10 99 01 Torque wrench 001 589 65 09 00 Socket |
