11. Using the pressure tool (6), push the bellows

(5) into its seat.

12. Turn the pressure tool (6) round and press

the thrust pieces (7) onto the adjusters.

R600717

7

6

BRAKE SYSTEM AND COMPONENTS

3-50

©

 200423

Removal and installation

5

ΧΦ65/75/85 series

6

3.25 REMOVING AND INSTALLING BRONZE BEARING BUSH OF

KNORR SB7000 BRAKE CALLIPER

Removing bronze bearing bush
1.

Remove the brake calliper.

2.

Remove washer (1).

3.

Remove guide bush (2).

4.

Remove the bellows (3).

5.

Remove the bronze bearing bush (4) using a
bearing bush extractor (5), special tool set
(DAF no. 1329494).

6.

Clean the bearing bush bore.

Fitting bronze bearing bush
1.

Fit the new bronze bearing bush (4) using
bearing bush extractor 5, special tool set
(DAF no. 1329494).

2

3

1

R600723

R600727

4

5

R600728

4

5

©

 200423

3-51

Removal and installation

BRAKE SYSTEM AND COMPONENTS

ΧΦ65/75/85 series

6

5

2.

Lock the bearing bush (4) in the brake
calliper (5) using a locking tool (6),
special tool set (DAF no. 1329494).
After the first locking operation, release the
locking tool, rotate 60

 and lock normally.

3.

Check the bearing bush for burrs.

4.

Apply lubricant to the bearing bush.
See "Technical data".

5.

Fit the bellows (3).

6.

Install the guide bush (2).

7.

Install the washer (1).

6

5

4

R600726

2

3

1

R600723

BRAKE SYSTEM AND COMPONENTS

3-52

©

 200423

Removal and installation

5

ΧΦ65/75/85 series

6

3.26 REMOVING AND INSTALLING BRONZE BEARING BUSH OF

KNORR SN7000 BRAKE CALLIPER

Removing bronze bearing bush
1.

Remove the brake calliper.

2.

Remove washer (1).

3.

Remove guide bush (2).

4.

Remove the bellows (3).

5.

Remove the bronze bearing bush (4) using a
bearing bush extractor (5), special tool set
(DAF no. 1329495).

6.

To do this, use the assembly of T14, T13,
T12 and a washer (1).

7.

Clean the bearing bush bore.

2

3

1

R600723

R600727

4

5

T12

T13

T14

R600759
