DAF CF65, CF75, CF85 Series . Manual - part 168

©

 200346

2-1

General

PREWAX TREATMENT

ΧΦ65/75/85 series

1

10

2. GENERAL

2.1 GENERAL

Introduction
PREWAX is a transparent, odourless, non-toxic
mixture of various types of wax and corrosion-
inhibiting chemicals which is vapour-sprayed into
all corrosion-sensitive areas.

It penetrates all seams and adheres to all
surfaces where it combines electrochemically
with the metal.
PREWAX does not drip, so there is no fouling of
the cab and floor. It can be sprayed without
difficulty into all cavities if the DAF equipment is
used. The equipment does not need to be
cleaned.

PREWAX TREATMENT

2-2

©

 200346

General

10

ΧΦ65/75/85 series

1

2.2 NOTES ON RE-TREATMENT

-

Thoroughly stir the PREWAX before use.

-

For optimal treatment, the temperature of
both the cab and the PREWAX must be
20

|C.

-

All holes required for re-treatment are
already present in the cab.

-

Treat cavities with a minimum pressure of 6
bar.

-

After treatment of seams and hinges, reduce
the air pressure to 3 bar (ideal pressure).

-

Make sure to re-install the ML plugs after
treatment.

-

Store the flexible spray pipe by hanging it in
vertical position.

-

Ensure that the area is properly ventilated
during treatment.

-

Use the ultraviolet light to check whether the
PREWAX has been applied properly.

©

 200346

2-3

General

PREWAX TREATMENT

ΧΦ65/75/85 series

1

10

2.3 TREATMENT OF THE CAB FRONT

Treat the front of the cab through the existing
openings.

K100002

PREWAX TREATMENT

2-4

©

 200346

General

10

ΧΦ65/75/85 series

1

2.4 TREATMENT OF THE DOORS

Remove the door upholstery and treat the door as
indicated in the illustration.

K100005
