4-1

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ65/65 (II) series

5

4. REMOVAL AND INSTALLATION

4.1 REMOVAL AND INSTALLATION, INTERIOR FILTER ELEMENT

Removing interior filter
1.

Open the grille.

2.

Push the locknut on the filter casing to one

side and remove the filter element.

Fitting interior filter
1.

Fit the filter element.

2.

Push the filter element into the locknut on the

filter casing.

3.

Close the grille.

Engine, cooling system and fuel system

K1 01 033

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-2

©

 200518

Removal and installation

5

ΧΦ65/65 (II) series

4.2 REMOVAL AND INSTALLATION, AIR FILTER ELEMENT

Removing the air filter element
1.

Loosen all the clamping brackets (1) of the

air filter cover (2).

2.

Remove the air filter cover (2).

3.

Remove the air filter element (3).

4.

Clean the inside of the air filter housing and

the air filter cover.

5.

When replacing the air filter element, reset

the air filter indicator, if fitted, by pressing the

button on the indicator.

Installing the air filter element

Note:

Only fit an original DAF fire retardant air filter

element.

The side of the fire retardant air filter element

contains the text "FIRE RETARDANT".

i400443

1

5

2

4

3

i400869

©

 200518

4-3

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ65/65 (II) series

5

1.

Fit the air filter element (3) in the air filter

housing.

2.

Fit the air filter cover. Note the arrow (4) on

the air filter cover (2).

3.

Fit all the clamping brackets (1).

4.

Check that the flexible sealing bellows (5) on

the air intake is not damaged. Replace if

necessary.

i400949

FI

R

E

RE

TA

RD

ANT

Use only DAF g

enuin

e p

arts

i400443

1

5

2

4

3

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-4

©

 200518

Removal and installation

5

ΧΦ65/65 (II) series

4.3 REMOVAL AND INSTALLATION, LUBRICATING OIL FILTER

To prevent skin injury, avoid

unnecessary contact with the

drained lubricating oil.

Be careful when changing the oil.

Hot oil may cause serious injuries.

Removing the lubricating oil filter
1.

Place a tray beneath the lubricating oil filter.

2.

Clean the area surrounding the filter element

if this is very dirty.

3.

Remove the filter element by turning it anti-

clockwise. Collect the oil that comes out.

4.

Remove the O-ring if it has not been

removed already.

Installing the lubricating oil filter
1.

Lightly oil the filter element sealing ring.

2.

Fill the filter element with clean oil. Use the

specified oil.

3.

Fit the filter element onto the housing.

Tighten the filter element until the sealing

ring abuts. Tighten the filter element a further

• to 1 turn by hand.

4.

Run the engine for a short time and check

that the lubricating oil filter is correctly

sealed.

5.

Check the oil level and correct if necessary.

Use the specified oil.

}

}

G0 00 207
