DAF LF45, LF55 Series. Manual - part 690

©

 200419

105

GEARBOX



3

3

1310469

Measuring plugs (M24x1.5; M12x1.5)

1310496

Calibration pin (pressure limiting valve/control valve

bore)

1310497

Calibration pin (pressure selector valve bore)

1310498

Calibration pin (heat exchanger selector valve bore)

1310469

1310496

1310497

1310498

GEARBOX

106

©

 200419

3

3

1310499

Calibration pin (pre-control valve bore)

1329341

Engine PTO driving tool

1329342

Engine PTO mounting ring

1329343

Measuring and assembly tool for engine PTO

1310499

1329341

1329342

1329343

©

 200419

107

GEARBOX



3

3

1329347

Mechanical shift control adjusting tool (MGS)

1329351

Auxiliary shaft bearing puller

1329352

Selector shaft seal and bush driving tool

1329353

Adapter for auxiliary shaft bearing bush driving tool

1329347

1329351

1329352

1329353

GEARBOX

108

©

 200419

3

3

1329354

Input shaft oil seal driving tool

1329355

Selector shaft bush driving tool

1329356

Selector shaft plug driving tool

1329358

Rear cover oil seal driving tool

1329354

1329355

1329356

1329358
