LF45/55 series
Removal and installation
STEERING BOX
4-21
24. Fit the universal joint to the steering box
input shaft. The groove (A) in the coupling
must be aligned with the mark (B) on the
steering-box input shaft.
Check that the universal joint is
correctly in place on the input shaft
so that the attachment bolt can be
fitted in the notch (C).
25. Fit a new, original attachment nut and bolt in
the universal joint.
26. Tighten the attachment bolt to the specified
tightening torque, see “Technical data”.
27. Install the steering rod.
28. If the vehicle has a steered trailing swivel
axle, fit the angle sensor to the steering
box.
29. Fill and bleed the steering gear.
30. Check the operation of the steering box
using the test case.
31. Take a test drive. During the test drive,
check that the steering gear is functioning
properly. After the test drive, check the
steering gear for leaks.
S7 00 594
A
B
C
