DAF 95XF. Manual - part 705
7
TECHNICAL DATA
Front axle(s), leading rear axle and steered trailing swivel axle
6-8
186N front axle track, configured as first front
axle in the case of two steered axles.
1
2
3
4
5
6
7
8
9
0
-1
0,5
-0,5
-1,5
1,5
2,5
3,5
4,5
5,5
-2
2
3
4
5
6
1
mm/m
186 N
x 1000 KG
S7 00 903
Alignment of steerable axles
Deviation in driving direction of the wheel of the
second front axle or leading rear axle in relation
to the front axle wheel:
-
check value
ᐔ 3 mm/m (angles A).
-
setting value
ᐔ 1 mm/m (angles A).
Measured on the left-hand wheels on a LHD
vehicle.
Measured on the right-hand wheels on a
RHD-vehicle.
S7 00 138
A
A
0
200424
