DAF 95XF. Manual - part 673

DIFFERENTIAL GEAR

210

©

 200419

8

8

1329498

Disassembly and assembly socket wrench for FTP hub
cap

1453122

Adjusting nut wrench for leaf-sprung trailing axle

1453141

Seal mounting tool

1453157

Pinion fitting dimension measuring tool (i.c.w. 1240087)

T1329498

T1453122

A800503

A800502

©

 200419

211

DIFFERENTIAL GEAR



8

8

1453173

Adjusting tool kit

1453175

Dummy pinion

1453176

Pinion depth bridge gauge

T00103

T00103

A800504

DIFFERENTIAL GEAR

212

©

 200419

8

8

©

 200419

213

CHASSIS



9

9

USE OF TABLE OF CONTENTS

At the beginning of every group there is a table of contents containing the following columns:

-

DAF code number of the special tool

-

relevant vehicle series

-

relevant main components or systems

-

page number of the figure

If a tool is used for a main component, system or vehicle series, this is indicated by a code in the
column (1-2-3-R).
This code has the following meaning:
1 - tool for carrying out maintenance work and repair work resulting from it.
2 - tool for frequently recurring work.
3 - tool for less frequently recurring work.
R - replacement part of a tool.

Note:
If a special tool does not occur in the relevant section, look in group 0 (General).
The special tool in question is then one that occurs in several groups.
