DAF 95XF. Manual - part 652

FUEL SYSTEM

126

©

 200419

4

4

1329350

Hose and 2x hose clamp (i.c.w. 0694833)

1329399

Injector test pipe (i.c.w. 0694966)

1329403

Hose and 2x hose clamp (for 1329320)

1329473

Injector connection pipe puller

1329350

1329399

1329403

1329473

©

 200419

127

FUEL SYSTEM



4

4

1329476

Voss fuel line T-piece

1453133

Fuel rail plug

1453151

Low-pressure fuel line sealing plug

1329476

i400878

i400879

FUEL SYSTEM

128

©

 200419

4

4

©

 200419

129

ELECTRICAL COMPONENTS



5

5

USE OF TABLE OF CONTENTS

At the beginning of every group there is a table of contents containing the following columns:

-

DAF code number of the special tool

-

relevant vehicle series

-

relevant main components or systems

-

page number of the figure

If a tool is used for a main component, system or vehicle series, this is indicated by a code in the
column (1-2-3-R).
This code has the following meaning:
1 - tool for carrying out maintenance work and repair work resulting from it.
2 - tool for frequently recurring work.
3 - tool for less frequently recurring work.
R - replacement part of a tool.

Note:
If a special tool does not occur in the relevant section, look in group 0 (General).
The special tool in question is then one that occurs in several groups.
