GEARBOX

102

©

 200419

3

3

1240497

Output shaft oil seal driving tool

1240498

Input shaft oil seal housing driving tool

1310459

Hydraulic spindle puller (i.c.w. 1310462)

1310460

Centring plate

1240497

1240498

1310459

1310460

©

 200419

103

GEARBOX



3

3

1310461

Adjusting tool for stator and rotor tapered roller bearing

1310462

Stator and rotor press-out tool (i.c.w. 1310459)

1310463

Gear mounting ring

1310464

Tapered roller bearing inner race guide sleeve

1310461

1310462

1310463

1310464

GEARBOX

104

©

 200419

3

3

1310465

Guide sleeve for fitting needle bearings

1310466

Range-change gear cover oil seal installer (i.c.w.
0694780)

1310467

Driving tool for stator and rotor

1310468

Output shaft oil seal driving tool

1310465

1310466

1310467

1310468

©

 200419

105

GEARBOX



3

3

1310469

Measuring plugs (M24x1.5; M12x1.5)

1310496

Calibration pin (pressure limiting valve/control valve

bore)

1310497

Calibration pin (pressure selector valve bore)

1310498

Calibration pin (heat exchanger selector valve bore)

1310469

1310496

1310497

1310498
