TECHNICAL DATA

XE-engine brake

7-2

7.2 TIGHTENING TORQUES

DEB
Valve cover attachment bolts

25 Nm

Rocker setting bolt lock nut

40 Nm

Bridge piece setting bolt lock nut

40 Nm

Rocker--bracket attachment bolts

110 Nm

Valve sleeve attachment bolts

30 Nm

Tighten the attachment bolts in the order
indicated

1

5

2

6

4

12

10

13

9

15

7

11

8

14

3

M200942

DEB set screw nut

25 Nm

Solenoid valve

20 Nm

Wiring harness attachment bolt

9 Nm

Spring plate fixing bolt

12.5 Nm

0

ᓻ 200351

4

95

XF series
