5
Modifications to the electrical installation from chassis number 0E459335
MODIFICATIONS TO THE ELECTRICAL INSTALLATION
2-1
2. MODIFICATIONS TO THE ELECTRICAL INSTALLATION FROM
CHASSIS NUMBER 0E459335
2.1 OVERVIEW OF MODIFICATIONS TO THE ELECTRICAL INSTALLATION
Modification/Chassis numbers
Electrical
system
From chassis
number
Modification
See sub-
diagram no.
Lighting
0E463970
Swedish lighting included in circuit diagram
Basic code numbers of tail lights C152 and
C153 changed to C022 and C023
8/9
Fuel line
heater
0E463970
Fuel line heater included in circuit diagram
44/45
Starting circuit
0E463970
Starter lock relay G303 added
1
Auxiliary
heating
0E477514
Electronic unit for auxiliary heating, Thermo
90, changed from D827 to D869
Thermo 90 auxiliary heating microrelay
(G300) added
41
Auxiliary
heating
0E479353
Control switch for Thermo 90
auxiliary-heating fan (E565)
(wire 4980 added to connection point 6)
Control switch for Thermo 90
auxiliary-heating fan (E576)
(wire 1201 disconnected from point 4)
41
Voith
retarder/ZF
intarder
0E460264
Retarder switch connection point (C799) for
connector changed
25/26
Cummins
Celect
0E462108
Electronic unit for DAF Cummins interface
(D804), wire 4049 disconnected from point
6 and connected to point 4
30
11
ǹ 0209
