INPUT SHAFT
DESCRIPTION
METRIC
SPECIFICATION
End Play
0.127-0.635mm
0.005-0.025 in.
TORQUE SPECIFICATIONS
DESCRIPTION
N·m
Ft. Lbs.
In. Lbs.
Bolt, Differential Cover-to-Case
19
—
165
Bolt, Differential Ring Gear-to-Case
95
70
—
Bolt, Differential Bearing Retainer-to-
Case
28
21
—
Bolt, Driveplate-to-Crankshaft
95
70
—
Bolt, Extension Housing/Plate-to-Case
28
21
—
Bolt, Oil Pan-to-Case
19
—
165
Bolt, Output Gear
271
200
—
Bolt, Output Gear Stirrup/Strap
23
17
—
Bolt, Oil Pump-to-Case
27
20
—
Bolt, Reaction Support-to-Case
27
20
—
Bolt, Solenoid/Pressure Switch
Assy.-to-Case
12
—
110
Bolt, Torque Converter-to-Driveplate
75
55
—
Bolt, Transfer Gear Cover
20
—
175
Bolt, Valve Body-to-Case
12
—
105
Fitting, Oil Cooler Line
12
—
105
Nut, Tranfer Gear
271
200
—
Tap, Transaxle Pressure
5
—
45
Screw, L/R Clutch Retainer
5
—
45
Screw, Solenoid/Pressure Switch Assy.
Connector
4
—
35
Screw, Valve Body-to-Transfer Plate
5
—
45
Sensor, Input Speed
27
20
—
Sensor, Output Speed
27
20
—
Sensor, Transmission Range Sensor
5
—
45
21 - 182
41TE AUTOMATIC TRANSAXLE
RS
41TE AUTOMATIC TRANSAXLE (Continued)
