(5) If the turning torque is within specifications, remove tools. Setup is complete. (6) If turning torque is not within specifications proceed with the following steps. (a) Remove differential bearing retainer from the transaxle case. (b) Remove the bearing cup from the differential bearing retainer using Tool 6062A. (c) Remove the existing shim from under the cup. (d) Measure the existing shim. sured, install a 0.05 mm (0.002 inch) thinner shim. (f) Install the proper shim under the bearing cup. Make sure the oil baffle is installed properly in the bearing retainer, below the bearing shim (g) Install the differential bearing retainer using Tool 5052 and C-4171. Seal the retainer to the t Adhesive Sealant and torque bolts to 28 N·m (250 in. lbs.). wrench, recheck the turning torque of the differential 194). The turning torque should be between 5 and 18 inch-pounds. Shim thickness need be determined only if any of the following parts are replaced: • Transaxle case • Differential carrier • Differential bearing retainer • Extension housing • Differential bearing cups and cones DIFFERENTIAL BEARING SHIM CHART PART NUMBER SHIM THICKNESS MM INCH 4659257 .980 0.0386 4659258 1.02 0.0402 4659259 1.06 0.0418 4659260 1.10 0.0434 4659261 1.14 0.0449 4659262 1.18 0.0465 4659263 1.22 0.0481 4659264 1.26 0.0497 4659265 1.30 0.0512 4659266 1.34 0.0528 4659267 1.38 0.0544 4659268 1.42 0.0560 4659269 1.46 0.0575 4659270 1.50 0.0591 4659271 1.54 0.0607 4659272 1.58 0.0623 4659273 1.62 0.0638 4659274 1.66 0.0654 4659275 1.70 0.0670 4659283 2.02 0.0796 4659284 2.06 0.0812 JR 40TE AUTOMATIC TRANSAXLE 21 - 125 FINAL DRIVE (Continued) |
