SKREEM VERIFICATION TEST - VER 1A
APPLICABILITY
1. Reconnect all previously disconnected components and connectors.
2. Obtain the vehicle’s unique Personal Identification Number (PIN) assigned to it’s original
SKIM. This number can be obtained from the vehicle’s invoice or Chrysler’s Customer Center
(1-800-992-1997).
3. NOTE: When entering the PIN, care should be taken because the SKREEM will only
allow 3 consecutive attempts to enter the correct PIN. If 3 consecutive incorrect
PIN’s are entered the SKREEM will Lock Out the DRB III for 1 hour.
4. To exit Lock Out mode, the ignition key must remain in the Run position continually for 1
hour. Turn off all accessories and connect a battery charger if necessary.
5. With the DRB III, select Theft Alarm, SKIM and Miscellaneous. Then select desired
procedure and follow the steps that will be displayed.
6. If the SKREEM has been replaced, ensure all of the vehicle ignition keys are programmed to
the new SKREEM.
7. NOTE: Prior to returning vehicle to the costumer, perform a module scan to be sure
that all DTC’s are erased. Erase any DTC’s that are found.
8. With the DRB III erase all DTC’s. Perform 5 ignition key cycles leaving the key on for at least
90 seconds per cycle.
9. With the DRB III, read the SKREEM DTC’s.
Are there any SKREEM DTC’s?
All
Yes
→ Repair is not complete, refer to appropriate symptom.
No
→ Repair is complete.
TIRE PRESSURE VERIFICATION TEST - VER 1 - SKREEM
APPLICABILITY
1. Adjust ALL tire pressure to recommended specifications.
2. Perform the SKREEM training as instructed in the System Description.
3. NOTE: Refer to SKREEM information for theft and RKE programming procedures.
Can the SKREEM auto learn the Sensor/Transmitter(s) and the TPMS indicator is OFF?
All
Yes
→ Repair is complete.
No
→ Refer to Diagnosing System Faults for this system.
VTSS VERIFICATION TEST - 1A
APPLICABILITY
1. Ensure all doors and the liftgate are closed.
2. Open the driver door.
3. Remove the ignition key (but keep in hand).
4. Lock the doors with RKE transmitter.
5. Close the driver door.
6. - If the VTSS Indicator Lamp flashes rapidly and after approximately 15 seconds changes to
a slower flash, the system is operational.
7. - If the Indicator fails to flash as described, there is a problem with the system. Select the
Identifying VTSS symptom from the Symptom List to troubleshoot.
Are any DTC’s present or is the original complaint still present?
All
Yes
→ Repair is not complete, refer to the appropriate symptom.
Perform VTSS VERIFICATION TEST - 1A.
No
→ Repair is complete.
1109
VERIFICATION TESTS
Verification Tests —
Continued
