(2) From under the vehicle loosen locking bolts (D) and (E) (Fig. 27). (3) Install the belt. Adjust belt tension with 1/2 in. breaker bar installed in adjusting bracket. See Belt (4) Tighten locking bolt (D) to 54 N·m (40 ft. lbs.) (Fig. 27). (5) Tighten locking bolt (E) to 28 N·m (250 in. lbs.). (6) Tighten pivot bolt (C) to 54 N·m (40 ft. lbs.). CLEANING AND INSPECTION WATER PUMP—2.0L ENGINES CLEANING Clean gasket mating surfaces as necessary. INSPECTION Replace water pump body assembly if it has any of these defects: (1) Cracks or damage on the body. coolant traces on the pump body. (3) Loose or rough turning bearing. engine block. (5) Impeller loose or damaged. ACCESSORY DRIVE BELT CLEANING Clean all foreign debris from belt pulley grooves. The belt pulleys must be free of oil, grease, and cool- INSPECTION Belt replacement under any or all of the following conditions is required: • Excessive wear • Frayed cords • Severe glazing across the ribbed side. These minor cracks are con- NOTE: Do not use any type of belt dressing or COOLING SYSTEM PRESSURE CAP CLEANING Use only a mild soap to clean the pressure cap. INSPECTION Hold the cap in your hand, right side up (Fig. 29). The vent valve at the bottom of the cap should open. Hold the cleaned cap in your hand, upside down. If any light can be seen between vent valve and the Fig. 27 Power Steering Belt Adjustment 1 – 1/2 INCH SQUARE OPENING BELT TENSION CHART ACCESSORY DRIVE BELTS GAUGE 2.0L ENGINES Air Conditioning New 667 N (150 lbs.) Used Belt: 356 N (80 lbs.) Power Steering Pump New 578 N (130 lbs.) Used Belt: 356 N (80 lbs.) JX COOLING SYSTEM 7 - 23 REMOVAL AND INSTALLATION (Continued) |
