8W-42 AIR CONDITIONING-HEATER
Component
Page
A/C Compressor Clutch . . . . . . . . . . . . . . . . 8W-42-7
A/C Compressor Clutch Relay . . . . . . . . . . . 8W-42-7
A/C Pressure Transducer . . . . . . . . . . . . . . 8W-42-7
Ambient Temperature Sensor . . . . . . . . . . . 8W-42-6
Automatic Temperature Control Module . . . 8W-42-4
Automatic Temperature Control
Power Module . . . . . . . . . . . . . . . . . . . . . 8W-42-5
Blend Door Actuator . . . . . . . . . . . . . . . . . . 8W-42-3
Blower Motor . . . . . . . . . . . . . . . . . . . . . . . 8W-42-5
Blower Motor Resistor Block . . . . . . . . . . . . 8W-42-2
Body Control Module . . . . . . . . 8W-42-2, 3, 4, 5, 6, 9
Evaporator Temperature Sensor . . . . . . . . . 8W-42-6
Fuse 7 (JB) . . . . . . . . . . . . . . . . . . . . . . . . . 8W-42-2
Fuse 17 (JB) . . . . . . . . . . . . . . . . . . . . . . 8W-42-2, 4
Fuse 19 (JB) . . . . . . . . . . . . . . . . . . . . . . . . 8W-42-4
Fuse 21 (JB) . . . . . . . . . . . . . . . . . . . . . . 8W-42-7, 8
Fuse 23 (JB) . . . . . . . . . . . . . . . . . . . . . . 8W-42-2, 5
Fuse B (PDC) . . . . . . . . . . . . . . . . . . . . . 8W-42-7, 8
Component
Page
Fuse E (PDC) . . . . . . . . . . . . . . . . . . . . . . . 8W-42-8
G100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-42-7
G105 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-42-8
G200 . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-42-2, 4, 5
G201 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-42-4
Headlamp Switch . . . . . . . . . . . . . . . . . . . . 8W-42-2
Instrument Cluster . . . . . . . . . . . . . . . . . 8W-42-4, 9
Junction Block . . . . . . . . . . . . . . . 8W-42-2, 4, 5, 7, 8
Manual Temperature Control Module . . . 8W-42-2, 9
Mode Door Actuator . . . . . . . . . . . . . . . . . . 8W-42-3
Park Lamp Relay . . . . . . . . . . . . . . . . . . . . 8W-42-2
Power Distribution Center . . . . . . . . . . . 8W-42-7, 8
Powertrain Control Module . . . . . . . . . . . 8W-42-7, 8
Radiator Fan High Relay . . . . . . . . . . . . . . 8W-42-8
Radiator Fan High/Low Relay . . . . . . . . . . . 8W-42-8
Radiator Fan Motor Assembly . . . . . . . . . . 8W-42-8
Recirculation Door Actuator . . . . . . . . . . . . 8W-42-3
Sun Sensor/VTSS SET LED . . . . . . . . . . . . 8W-42-6
