9640 REAR BOW TRAVEL SENSOR (BASE SIDE) +/- CIRCUIT OPEN/SHORT TO GROUND (CONTINUED) 7. Rear Bow Travel Sensor (Base Side) (+) Circuit Shorted to Ground Turn the ignition off. Disconnect the Power Top Control Module C1 harness connector. Measure the resistance between ground and the Rear Bow Travel Is resistance below 100 kohms? Yes >> Repair the Rear Bow Travel Sensor (Base Side) (+) circuit for a short to ground. Perform POWER TOP CONTROL MODULE VERIFICA- No >> Replace the Power Top Control Module.(Refer to 8 - ELECTRICAL/ELECTRONIC CONTROL MODULES/ POWER TOP CONTROL MODULE - REMOVAL). Perform POWER TOP CONTROL MODULE VERIFICA- 8. INTERMITTENT WIRING AND CONNECTORS The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible Note: Check connectors — Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Note: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes >> Repair as necessary. Perform POWER TOP CONTROL MODULE VERIFICATION TEST. No >> The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition. ZH CONVERTIBLE TOP 23 - 87 |
