1. Disconnect the negative battery cable. 2. Remove the shifter cover trim panel. (Refer to 23 - BODY/INTERIOR/CENTER CONSOLE - REMOVAL). 3. Disconnect the power window switch harness con- nector (1). 4. Squeeze the clips together and remove the power window switch from the shifter cover trim panel. INSTALLATION 1. Install the power window switch to the shifter cover trim panel. 2. Connect the power window switch harness connec- tor (1). 3. Install the shifter cover trim panel. (Refer to 23 - BODY/INTERIOR/CENTER CONSOLE - INSTAL- 4. Connect the negative battery cable. ZH POWER WINDOWS - SERVICE INFORMATION 8N - 125 |
