TRIM LACE
REMOVAL
1. Remove trim lace (2) by holding one end of the
trim lace at the butt joint and pulling horizontally
into the opening until lace is completely loose from
the headliner/sunroof joint.
INSTALLATION
1. Place butt joint of trim lace into position starting at
the drivers side middle of the opening at the butt
joint notch in the u-frame.
2. Push lace into position.
3. Ensure that the corner radii is fully engage.
4. Once the trim lace is attached to sunroof module
using a trim stick C-4755 or equivalent, begin tuck-
ing the headliner under the lip on the trim lace
working all the way around the opening. When
installing a new trim lace, begin tucking the head-
liner under the lip as the tear cord (1) is removed
working all the way around the opening.
