16. Disconnect the engine harness electrical connectors (7) from the right side fuel injectors. Fig. 79: View Of Engine Wiring Harness, Clip, Bolt & Connector 17. Remove the engine harness clip (1) bolt (3).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
18. Disconnect the engine harness electrical connector (2) from the engine coolant temperature (ECT) sensor. 19. Gather the engine harness branches and tie the harness up out of the way to the cowl panel. Fig. 80: View Of Brake Booster Vacuum Hose & Booster Fitting 20. Reposition the brake booster vacuum hose clamp at the booster. 21. Remove the brake booster vacuum hose from the booster fitting. 22. Secure the brake booster vacuum hose to the intake manifold.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 81: View Of EVAP Canister Purge Tube & Quick Connect Fitting 23. Disconnect the EVAP canister purge tube (1) quick connect fitting from the EVAP canister purge solenoid. Refer to Plastic Collar Quick Connect Fitting Service . 24. Disconnect the fuel feed line quick connect fitting (2) from the fuel rail. Refer to Metal Collar Quick Connect Fitting Service .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 82: View Of PCV Hose 25. Remove the positive crankcase ventilation (PCV) hose from the intake manifold fitting.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
